C++ で連立一次方程式を解く(LU分解法)
連立一次方程式
を行列で表すと, こんな感じ
このとき
とすると, 最初の連立方程式は と表すことができる.
このとき となる 上三角行列 , 下三角行列 を考えると,
であり, とおくと となる.
LU分解法では, 係数行列 を上三角行列 , 下三角行列 に分解し,
から を求め, から を求める.
上三角行列 は, ガウスの消去法で使った上三角行列そのもので,当然求め方も同じ.
下三角行列 は, ガウスの消去法の計算途中で使った値を保存しておくだけ.
なので, ガウスの消去法とほとんど同じだが, 行列 の値だけを変えて繰り返し実行する場合に使う.
#include <iostream> #include <iomanip> #include <math.h> using namespace std; void decomp(double a[4][4], double b[4], double x[4]); int main() { double a[4][4] = {{-1,-2,7,-2},{1,-1,-2,6},{9,2,1,1},{2,8,-2,1}}; double b[4] = {8,17,20,16}; double x[4] = {0,0,0,0}; decomp(a,b,x); for (int i = 0;i<=3;i++) cout << setw(12) << fixed << setprecision(10) << x[i] << "\t"; cout << endl; return 0; } void decomp(double a[4][4], double b[4], double x[4]) { // ピボット選択 int p[4] = {0,1,2,3}; for(int pivot = 0; pivot < 4; pivot++) { // 各列で 一番値が大きい行を 探す int col = pivot; int max_row = pivot; double max_val = 0; for (int i = p[pivot]; i < 4; i++) { int row = p[i]; if (fabs(a[row][col]) > max_val) { // 一番値が大きい行 max_val = fabs(a[row][col]); max_row = row; } } // 一番値が大きい行と入れ替え if (max_row != p[pivot]) { int tmp = p[pivot]; p[pivot] = max_row; p[max_row] = tmp; } } // 並べ替え後の状態を確認 for (int i = 0; i < 4; i++) { for (int j = 0; j < 4; j++) cout << setw(14) << fixed << setprecision(10) << a[p[i]][j] << "\t"; cout << setw(14) << fixed << setprecision(10) << b[p[i]] << "\t"; cout << endl; } cout << endl; // 前進消去 for (int pivot = 0; pivot < 3; pivot++) { int p_row = p[pivot]; int p_col = pivot; for (int i = pivot+1; i < 4; i++) { int row = p[i]; double s = a[row][p_col] / a[p_row][p_col]; for (int col = pivot; col < 4; col++) a[row][col] -= a[p_row][col] * s; // これが 上三角行列 a[row][p_col] = s; // これが 下三角行列 // b[row] -= b[p_row] * s; // この値は変更しない } } // 前進消去後の状態を確認 for (int i = 0; i < 4; i++) { for (int j = 0; j < 4; j++) cout << setw(14) << fixed << setprecision(10) << a[p[i]][j] << "\t"; cout << setw(14) << fixed << setprecision(10) << b[p[i]] << "\t"; cout << endl; } cout << endl; // Ly=b から y を求める double y[4] = {0,0,0,0}; for (int i = 0; i < 4; i++) { int row = p[i]; for (int col = 0; col < i; col++) b[row] -= a[row][col] * y[p[col]]; y[row] = b[row]; } // y の 値 for (int i = 0;i<=3;i++) cout << setw(12) << fixed << setprecision(10) << y[p[i]] << "\t"; cout << endl << endl; // Ux=y から x を求める for (int i = 3; i >= 0; i--) { int row = p[i]; for (int col = 3; col >= i + 1; col--) y[row] -= a[row][col] * x[col]; x[i] = y[row] / a[row][i]; } }
9.0000000000 2.0000000000 1.0000000000 1.0000000000 20.0000000000 2.0000000000 8.0000000000 -2.0000000000 1.0000000000 16.0000000000 -1.0000000000 -2.0000000000 7.0000000000 -2.0000000000 8.0000000000 1.0000000000 -1.0000000000 -2.0000000000 6.0000000000 17.0000000000 9.0000000000 2.0000000000 1.0000000000 1.0000000000 20.0000000000 0.2222222222 7.5555555556 -2.2222222222 0.7777777778 16.0000000000 -0.1111111111 -0.2352941176 6.5882352941 -1.7058823529 8.0000000000 0.1111111111 -0.1617647059 -0.3750000000 5.3750000000 17.0000000000 20.0000000000 11.5555555556 12.9411764706 21.5000000000 1.0000000000 2.0000000000 3.0000000000 4.0000000000
